ONKA 10mm2 PE spring collecting connector terminal for DIN rail 2-wire gray, 1020300
- Regular price
- €3,64
- Regular price
-
- Sale price
- €3,64
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
Pre-order product
- Description
- Payment methods
- Warranty
PE spring terminal block / Terminal for DIN rail 2-wire green-yellow, ONKA, made in Turkey
Compact installation connectors for rail from ONKA provide great possibilities for connecting different conductors of various cross-sections. The transparent housing allows for easy verification of the correct arrangement of conductors. Original ONKA quick connectors offer convenience during installation and 100% reliability of the connection.
Technical parameters
Cross-section of connected single-core conductor up to: 10mm2
Color: Green-yellow (camouflage)
Insulating material of the main housing: polyamide (PA6.6)
Contact / bridge material: CK45 steel / copper
Connection position: from above / top
Cable strip length: 12mm
Type of electrical connection: spring clamp
Rated voltage: 750V
Operating temperature range: -40°C... 140°C
Mounting method: DIN rail 35 mm
Standard: EN-60947-7-1
