ONKA 70mm2 M8 Screw terminal block connector for DIN rail with protective cover, gray, 1030045

M8, 70mm2, threaded connector/terminal block / terminal for DIN rail with protective cover, gray, ONKA, made in Turkey

Compact installation terminal blocks from ONKA provide great connection possibilities for conductors of various cross-sections. The transparent housing allows for easy verification of the correct arrangement of conductors. Original ONKA quick connectors facilitate installation and guarantee 100% reliability of the connection.

Technical specifications

Cross-section of connected single-core conductor up to: 70mm2
Color: gray
Insulating material of the main housing: polyamide (PA6.6)
Contact / bridge material: CK45 steel / copper
Connection position: Side / Side
Rated voltage: 1000V
Rated current: 192A
Operating temperature range from: -40°C
Operating temperature range to: 140°C
Mounting method: DIN rail 35 mm
